Thirty O³ Plus

Our largest ozone generator, equipped with a power of 30 grams of ozone per hour and additionally with a UV lamp. It can also be operated with 10g/h or 20g/h ozone output and is suitable for room sizes up to 160 square meters and for any car.

Immediately available
Delivery time 3 to 5 workdays

599,90  incl. VAT

    • 99.9 €
    • 40 €

Product data

Ozone - What is it actually?

Ozone is a natural molecule that has been used for decades to eliminate viruses, germs and bacteria from the air.

In nature, ozone is mainly found in higher layers of the sky.

With the help of an ozone generator, ozone is artificially produced and used, for example, to eliminate odours. When an ozone molecule meets odour-forming molecules, the ozone molecule changes their cell structures and an odour-neutral molecule is formed. This mechanism is also effective against viruses and bacteria in the air. This is precisely why ozone is used as a sterilizer, especially in industry.

Our advantages:
In hotels, restaurants and in passenger transport there is a rather high and regularly changing number of people, which is why it is so important that sterilization is carried out there on a regular basis.

With the help of our ozone generators, you can disinfect and sterilize even the most inaccessible places and rooms without the need for additional personnel. It is very simple: Place the device in the room to be treated, program the desired operating time and start the ozone generator outside the room using the radio remote control.

  • Flexible application possibilities
  • Chemical-free germ and virus elimination
  • Safe application due to radio remote control
  • High ozone output
  • Compact design
  • Made in Germany
Ozone Nominal power 10, 20 or 30 g/h (adjustable)
Room size up to 160 sqm
Power consumption 280 W
UV lamp Yes
Air flow rate:

177 m³/h

Height 26.5 cm
Wide 20.5 cm
Depth 18.0 cm
Weight 4.8 kg
Connection 220 - 240V 50/60Hz
Housing Stainless steel
Scope of delivery 1 x Ozone generator 30 grams per hour
1 x Power cord
2 x radio remote control
2 x fuse
1 x German instruction manual

Accessories

Downloads

Manual

Car handling instructions

Frequently asked

Ozone is sometimes called "activated oxygen". It is the triatomic form of oxygen that we breathe in its diatomic form. Ozone is the second most powerful disinfectant in the world and safely removes odors without residue.
Interestingly, ozone occurs quite frequently in nature, e.g. from a lightning strike during a thunderstorm. In fact, that " spring rain" smell we notice after a thunderstorm results from the natural production of ozone. Ozone is probably more familiar in the context of the ozone layer that envelops our planet. This ozone is produced by the sun's ultraviolet rays. It protects us from the sun's UV rays and acts as a UV filter.

Yes, by the smell. Ozone is an invisible gas with a characteristic odor. A particularly sensitive human nose can possibly detect ozone at a concentration of 0.0076 parts per million (ppm), but at the latest at 0.03 ppm everyone should be able to smell ozone. In comparison, the air quality limit for harmlessness is 0.06 ppm. This means that ozone can be smelled before it reaches an unhealthy concentration. At elevated concentrations above 0.06 ppm, ozone may begin to smell unpleasant to sensitive noses. The big advantage, in rooms with increased concentration nobody would stay voluntarily for a long time. It would be completely natural to leave the room. .

Although ozone is a very strong oxidant, it has a very short life span. In the process of odor elimination, the extra oxygen atom is also consumed. The use of ozone is safe because we can smell ozone even in very low concentrations. So, if ozone is released during cleaning, it would be noticed immediately because the smell of ozone at a concentration of 1.5 ppm is considered so disgusting that we would be able to stand it for a long time in such an environment. It is just as if we were entering a room full of smoke.

There are generally two methods to produce ozone. The ultraviolet radiation and the silent electrical discharge. Most use the silent electrical discharge, which basically simulates a lightning strike. Ozone generation using ultraviolet lamps are rarely used nowadays because the process is inefficient. The ozone is extracted from the ambient air.

Practically all areas of application have something to do with cleaning, hygiene, sterilisation, disinfection or odour control in air or water. Therefore, the range of ozone is a large field of application.

  • Drinking water treatment
  • Water treatment: whirlpools, swimming pools, aquacultures, etc.
  • Waste water treatment: textile industry, pharm. industry, sewage treatment plants, etc.
  • Room air purification: Air disinfection, removal of volatile organic compounds (VOC), e.g. in clean rooms
  • Odour neutralisation: smell of fire, smoke, cigarettes, corpses etc. in rooms or vehicles, biogas plants, waste management plants, waste rooms, grease separators, fermenters, waste gas purification plants.
  • Remediation of rooms: mould remediation, odour control
  • Disinfection of objects, rooms or in washing machines
  • Production plant cleaning: rinsing and cleaning of production plants, removal of aromatic substances, cleaning of returnable bottles, hygiene measures in the beverage and food industry (dairies, breweries, etc.)
  • Bleaching of paper and textiles
  • Deionization of water: e.g. rinsing water in the semiconductor industry
  • Cosmetics: Skin steaming for cleansing, e.g. with acne
  • Ozone therapy: therapy method in alternative medicine

Once ozone has been formed by the generator and is discharged into the room, a portion immediately decays back to oxygen. This process is caused by the more natural decay of the chemical instability of ozone. The process just mentioned is accelerated by the presence of walls, wallpaper, etc. Neutralization of odor by organic material also removes ozone. Moreover, ozone has a short half-life, which means that within a maximum of 30 minutes the ozone content in the treated room is halved. This in turn means that after each additional 30 minute period there will be half as much ozone left as there was at the beginning of the 30 minute period. This is similar to a degression of 16; 8; 4; 2; 1. In practice, the half-life is usually less than 30 minutes, due to bacterial and other contaminants in the air. Consequently, ozone, although very powerful, does not last long in indoor air.

Yes, ozone permanently eliminates the bad smell. If the odour still does not disappear after treatment, then the application time was too short or the cause of the odour has not been eliminated.

Yes! Ozone can kill bacteria, fungi and mold spores in the air and on surfaces. This eliminates the most common causes of food spoilage. Some foods are treated directly, some are treated only in the surrounding air during storage, processing, protective atmosphere

The ozone generator uses ceramic plates for ozone generation, which are subject to wear. The service life of these ceramic plates is approx. 1,500 hours, after which they must be replaced.
This depends on the size of the area to be treated and the capacity of the ozone generator. In fact, it is difficult to give an exact treatment duration because different odours can penetrate materials to different depths. This then requires different treatment durations. Please start with small treatment times.

Ozone is very reactive and has a half-life of about 30 minutes. Thus, the ozone level decreases very quickly. The treated rooms must not be entered for at least 6 hours after the end of the ozone generator's runtime and then ventilated for another 2 hours.

When treating vehicles, the ozone generator should be placed in the passenger footwell. The ventilation should be set to recirculation and level 1. In the case of a sedan, it is important to fold down the rear seat bench so that the ozone also reaches the trunk. Please treat cars with ozone only outdoors and lock it so that nobody opens the car during the treatment. After the treatment, please wait for 1 hour and then ventilate the vehicle well for 2 hours. Please read the handling instructions for motor vehicles.
